Chromium Carbide Overlay Pipe


Chromium Carbide overlay pipe is a combination of mild steel base material onto which a highly abrasive resistant welded overlay is deposited with an open arc process. We use an oscillating table with one welding head to arc weld the chromium carbide to the base material. We can handle diameters from 6" up to 24" after which we fabricate the pipe from our Chromium Carbide overlay plate. The overlay is deposited perpendicular to the flow of material through the pipe resulting in a longer wear life. Our Chromium Carbide overlay Elbows are lined with the same deposited material except welded by hand. Overlay is deposited in either a single pass application which is 1/8" to 3/16" thickness or a double pass application which is 1/4" to 3/8" in thickness. Wear life of our Overlay pipe can be up to 15 to 1 over standard wear pipe. The longer wear life of our products reduce maintenance hassles, costly down time, and material loss.


Standard Sizes

Diameters Base pipe
from 6" Std Wall pipe
To 24" Hvy wall pipe
Tubing sizes-( to result in standard
pipe ID sizes)


Available Finishes
We product our overlay pipes in single pass (1/8"-3/16"), double pass (1/4"-3/8"). We also manufacture overlay plate on a variety of base materials including A36 Mild Steel, 304 & 316 Stainless Steel.

Applications

Chrome Carbide overly pipe can be used in any situation suited for wear pipe. This highly abrasive resistant pipe can be installed as easily as mild steel pipe.

Slurry Piping Ash Handling
Clinker piping Cullet Glass handling


Contact: Belinda Renteria-Sales Manager



Chrm Carbide Ovly Pipe-Part2



CARIBEL ALLOYS, LLC
Metal Repair Specialists
Chromium Carbide Overlay Pipe

Chemical Properties ( Typical)


Element %

C 5.5-7.00
Mn 2.10
P 0.022
S 0.016
Si 0.50
Cr 27.0-30.0


Mechanical Properties ( Typical)

Hardness 55-60 Rockwell C (650) BHN
Max Service Temp 1250 ° F
Tensile strength Varies per base material
Yield Strength Varies per base material
G65 Weight Loss 0.15g
